Connex Connector Product Specification Sheet

Part Number  182324 Family/Series: UHF/Mini-UHF Coaxial Connectors Product Type: Mini-UHF Series Description: Right Angle 2-Piece Crimp Plug

Specifications

Electrical

Cable Group 01A    Cable Types: 55 / 142 / 223 / 400

Finish Nickel

Insulation Delrin

Impedance 50 ohms

Crimp Tool A

Remark  Cable center conductor soldered to pin directly

Schematic Drawing
