 Connex Connector Product Specification Sheet
Part Number Add part number 112622 to your Quote. 112622
Family/Series: BNC Coaxial Connectors
Product Type: Printed Circuit Board/Receptacles
Description: Straight PCB Edge Mount Jack - End Launch
square flange

Specifications
Electrical
Cable Group N/A
Finish Nickel
Insulation Teflon
Impedance 75 ohms
Crimp Tool N/A
Schematic Drawing
Connex part number 112622 schematic
